BH46Y Woodworking Panel Machine Pre-milling Automatic Edge Banding Machine

Model

Workpiece length

≥150mm

Speed

18-22-24m/min

Workpiece width

≥80MM

Air pressure

0.6mpa-0.8mpa

Smallest workpiece

150-80mm

Power

16.5kw

Workpiece thickness

10-55mm

Size

6680*1000*1650

Band thickness

0.4-3mm

Weight

2.2T

Pre-milling power

2.2kw*2

Glue heating power

1.8kw

Panel pre-heating power

0.3kw

Glue pot transfer power

0.75kw

Conveyor transfer power

2.2kw

End cutting power

0.55kw*2

Rough trimming power

0.75kw*2

Fine trimming power

0.75kw*2

Buffing power

0.18kw*2
